Luteal blood flow and luteal function
Blood flow in the corpus luteum (CL) is associated with luteal function. The present study was undertaken to investigate whether luteal function can be improved by increasing CL blood flow in women with luteal phase defect (LFD).
Blood flow impedance in the CL was measured by transvaginal color-pulsed-Doppler-ultrasonography and was expressed as a resistance index (RI). The patients with both LFD [serum progesterone (P) concentrations < 10 ng/ml during mid-luteal phase] and high CL-RI (≥ 0.51) were given vitamin-E (600 mg/day, n = 18), L-arginine (6 g/day, n = 14) as a potential nitric oxide donor, melatonin (3 mg/day, n = 13) as an antioxidant, or HCG (2,000 IU/day, n = 10) during the subsequent menstrual cycle.
In the control group (n = 11), who received no medication to increase CL blood flow, only one patient (9%) improved in CL-RI and 2 patients (18%) improved in serum P. Vitamin-E improved CL-RI in 15 patients (83%) and improved serum P in 12 patients (67%). L-arginine improved CL-RI in all the patients (100%) and improved serum P in 10 patients (71%). HCG improved CL-RI in all the patients (100%) and improved serum P in 9 patients (90%). Melatonin had no significant effect.
Vitamin-E or L-arginine treatment improved luteal function by decreasing CL blood flow impedance. CL blood flow is a critical factor for luteal function.
KeywordsMelatonin Corpus Luteum Melatonin Treatment Luteal Function Flow Velocity Waveform
During corpus luteum formation, active angiogenesis occurs after the ovulatory LH surge, and the corpus luteum becomes one of the most highly vascularized organs in the body [1, 2, 3, 4, 5, 6, 7]. Blood flow in the corpus luteum is important for the development of the corpus luteum and maintenance of luteal function [7, 8, 9, 10, 11, 12]. Adequate blood flow in the corpus luteum is necessary to provide luteal cells with the large amounts of cholesterol that are needed for progesterone synthesis and to deliver progesterone to the circulation. Color Doppler ultrasonography is a useful and noninvasive technique for evaluating ovarian vascular function, allowing visual observation of the blood flow within the corpus luteum [13, 14, 15, 16]. Blood flow in the corpus luteum measured by color Doppler ultrasonography is well associated with luteal function [13, 14, 15, 16, 17, 18, 19, 20, 21].
We recently reported changes in blood flow in the human corpus luteum throughout the luteal phase and a close relationship between luteal blood flow and luteal function . Interestingly, luteal blood flow was significantly correlated with serum progesterone concentrations during the mid-luteal phase, and luteal blood flow was significantly lower in women with luteal phase defect than in women with normal luteal function, suggesting that low blood flow of the corpus luteum is associated with luteal phase defect. We, therefore, decided to study whether luteal phase defect can be improved by increasing luteal blood flow.
For this purpose, we focused on vitamin E and a potential nitric oxide (NO) donor, L-arginine, to increase luteal blood flow. Vitamin E has been shown to improve capillary blood flow in a variety of organs not only by inhibiting the breakdown of lipids in red blood cell membranes [22, 23] but also by protecting the endothelium from oxidative stress [24, 25]. NO release by vascular endothelial cells via endothelial NO synthase (eNOS) leads to the relaxation of vascular smooth muscle, mainly by activating cyclic guanosine monophosphate (cGMP) . L-arginine, a substrate of NO, increases hepatic and limb blood flow [27, 28]. In the present study, in order to examine the role of luteal blood flow in the regulation of luteal function, we investigated whether luteal function can be improved by increasing luteal blood flow in patients with luteal phase defect.
It has also been reported that decreased blood flow causes oxidative stress in a variety of organs [29, 30, 31]. Oxidative stress is well known to inhibit luteal function [30, 31]. In fact, the decrease in ovarian blood flow inhibits luteal function through oxidative stress in rats . Therefore, we further examined the possibility that the decrease in blood flow of the corpus luteum inhibits luteal function through oxidative stress in patients with luteal phase defect.
The project was reviewed and approved by Institutional Review Board of Yamaguchi University Graduate School of Medicine. Informed consent was obtained from all the patients in this study.
A total of 66 women who had both luteal phase defect and high blood flow impedance of the corpus luteum [corpus luteum-resistance index (CL-RI) ≥ 0.51] were recruited into this study. When serum progesterone concentrations were < 10 ng/ml during the mid-luteal phase, the patient was diagnosed as having a luteal phase defect in this study. CL-RI was measured during the mid-luteal phase, and the cutoff value was determined as described below. The mean age was 32.4 ± 4.3 years (mean ± SD), with a range of 24–41 years. The patients were non-smokers and free from major medical illness including hypertension; they were excluded if they had myoma, adenomyosis, congenital uterine anomaly, or ovarian tumors or if they used estrogens, progesterone, androgens, or had chronic use of any medication, including nonsteroidal anti-inflammatory agents or anticonvulsants.
Blood flow in the corpus luteum was measured as reported previously  using a computerized ultrasonography with an integrated pulsed Doppler vaginal scanner [Aloka ProSound SSD-3500SV and Aloka UST-984-5 (5.0 MHz) vaginal transducer, Aloka Co. Ltd, Tokyo, Japan]. The high pass filter was set at 100 Hz, and the pulse repetition frequency was 2–12 kHz, for all Doppler spectral analyses. After the endovaginal probe was gently inserted into the vagina, adnexal regions were thoroughly scanned. The ovary was identified, and color signals were used to detect the area with the highest blood flow within the corpus luteum. Blood flow was identified in the peripheral area of the corpus luteum . The pulsed Doppler gate was then placed on that area to obtain flow velocity waveforms. An acceptable angle was less than 60°, and the signal was updated until at least four consecutive flow velocity waveforms of good quality were obtained. Blood flow impedance was estimated by calculating the resistance index (RI), which is defined as the difference between maximal systolic blood flow (S) and minimal diastolic flow (D) divided by the peak systolic flow (S-D/S). Blood flow impedances were examined in the corpus luteum during the mid-luteal phase (6–8 days after ovulation). The day of ovulation was determined by urinary LH, transvaginal ultrasonography and basal body temperature records. Since the interobserver coefficient of variation for Doppler flow measurements in the present study was less than 10%, which is consistent with the reports by Ziegler et al.  and Miwa et al. , the Doppler flow measurements were judged to be reproducible.
In order to investigate whether vitamin E or L-arginine treatment has a potential to increase luteal blood flow and to improve luteal function in patients with luteal phase defect, the patients who showed both luteal phase defect and high CL-RI (≥ 0.51) during the mid-luteal phase (6–8 days after ovulation) were given vitamin E (600 mg/day, 3 times per day orally; Eisai Co., Ltd., Tokyo, Japan; n = 18), or L-arginine (6 g/day, 4 times per day orally; Now Foods, IL, USA; n = 14) during the luteal phase of the subsequent menstrual cycle.
Decreased ovarian blood flow is reported to inhibit luteal function via oxidative stress . Therefore, to examine a possibility that the decrease in luteal blood flow inhibits luteal function through oxidative stress in women with luteal phase defect, melatonin (3 mg at 22:00 hr orally; KAL, Park City, UT, USA; n = 13) was given as an antioxidant during the luteal phase of the subsequent menstrual cycle. We confirmed that administration of 3 mg of melatonin works as an antioxidant and suppresses oxidative stress in the human ovulatory follicle .
Another 10 patients received luteal support with HCG injection (2,000 IU/day, on days 3 and 5 after ovulation; Gonatropin; Asuka Co., Ltd., Tokyo, Japan).
As controls, 11 patients with both luteal phase defect and high CL-RI (≥ 0.51) during the mid-luteal phase received no medication during the subsequent menstrual cycle.
To evaluate the effect of those treatments, serum progesterone concentrations and CL-RI were measured during the mid-luteal phase (6–8 days after ovulation). Ultrasonogrphy was performed before blood sampling for serum progesterone measurement.
Venous blood was taken for the determination of serum progesterone concentrations on the day of the Doppler examination during the mid-luteal phase. Progesterone concentrations were measured by enzyme immunoassay (ST AIA-PACK PROG, Tosoh Co., Ltd., Japan) as reported previously . The minimal detectable concentration is estimated to be 0.1 ng/ml. Intra-assay and inter-assay coefficients of variation were 9.9% and 11.3%, respectively.
Single regression analysis, Wilcoxon signed-ranks test, and chi-squared test with Bonferroni correction were carried out using the computer program SPSS for windows 13.0. A value of P < 0.05 was considered significant.
Vitamin E treatment
Effects of vitamin E, L-arginine, melatonin, or HCG on corpus luteum resistance index and serum progesterone concentrations in patients with luteal phase defect.
Serum P (ng/ml)
No. of < 0.51
No. of ≥ 10 ng/ml
L-arginine treatment improved CL-RI in all the patients (100%), and 10 patients out of 14 (71%) developed serum progesterone concentrations of more than 10 ng/ml (Table 1). Compared with the control, L-arginine significantly improved CL-RI and serum progesterone concentrations (Table 1). L-arginine also significantly decreased CL-RI and increased serum progesterone concentrations between the treatment cycle and the previous cycle (Table 1).
Melatonin treatment improved CL-RI in 4 patients out of 13 (31%) and improved serum progesterone concentrations in 5 patients (38%) (Table 1). These effects were not significant compared with the control (Table 1). Melatonin treatment caused a significant increase in serum progesterone concentrations in the treatment cycle compared with the previous cycle, but the serum progesterone levels were less than 10 ng/ml (Table 1).
HCG treatment improved CL-RI in all the patients (100%), and 9 patients out of 10 (90%) developed serum progesterone concentrations of more than 10 ng/ml (Table 1). Compared with the control, HCG significantly improved CL-RI and serum progesterone concentrations (Table 1). HCG also significantly decreased CL-RI and increased serum progesterone concentrations between the treatment cycle and the previous cycle (Table 1).
Luteal phase defect has been implicated as a cause of infertility and spontaneous miscarriage. Previous reports including our recent report suggest that luteal phase defect is associated with high blood flow impedance of the corpus luteum, because luteal blood flow impedance in women with luteal phase defect during the mid-luteal phase was significantly higher than it was in women with normal luteal function [13, 14, 16, 19, 20], and CL-RI was negatively correlated with serum progesterone concentrations during the mid-luteal phase. The present study showed that treatments with vitamin E or L-arginine significantly improved CL-RI and luteal function in patients with luteal phase defect and high CL-RI. Most of the patients whose CL-RI was improved by vitamin E or L-arginine showed improvement of luteal function. Furthermore, in our unpublished data, administration of progesterone as a luteal support for the patients with both luteal phase defect and high CL-RI did not improve CL-RI during the mid-luteal phase, suggesting that progesterone does not influence luteal blood flow impedance. It is, therefore, likely that vitamin E or L-arginine improves luteal function by decreasing luteal blood flow impedance. The present result that decreasing luteal blood flow impedance improved luteal function strongly suggests that high blood flow impedance of the corpus luteum is involved in the pathophysiology of impaired luteal function in patients with luteal phase defect. In other words, luteal blood flow is a critical factor for luteal function.
Although there are no well-established methods for increasing luteal blood flow, the present results appear to be consistent with previous reports by ourselves and others that vitamin E, L-arginine, or sildenafil citrate (Viagra) improved endometrial growth in patients with a thin endometrium by increasing uterine artery blood flow [33, 35, 36, 37].
Decreased ovarian blood flow is reported to inhibit luteal function via oxidative stress . Oxidative stress is well known to inhibit luteal function [30, 31]. It is of interest to note that vitamin E acts as an antioxidant. The present result revealed that melatonin used as an antioxidant did not improve luteal blood flow impedance or luteal function, suggesting that vitamin E works via decreasing luteal blood flow impedance rather than by acting as an antioxidant.
Interestingly, HCG improved luteal blood flow impedance as well as L-arginine. Although it is unclear how HCG increases luteal blood flow, it may work through vasoactive substances because there is some evidence that luteal phase defect is caused by the altered regulation of luteal blood flow during the mid-luteal phase . Vasoactive substances such as NO, endothelin, or angiotensin have been reported to be involved in luteal function [11, 38, 39, 40, 41]. HCG increases eNOS expression in the ovary of the rat and sheep [42, 43], and increases rat ovarian blood flow via locally produced NO . Further studies are needed to elucidate the relationship between luteal blood flow and vasoactive substances in the corpus luteum.
The present study is, to our knowledge, the first report to show a close relationship between luteal blood flow impedance, luteal function, and treatments that improve luteal blood flow. Treatments that improve luteal blood flow seem to improve luteal function in patients with both luteal phase defect and high luteal blood flow impedance. In other words, luteal blood flow is a critical factor for luteal function. However, the present study is a pilot study with a small number of subjects. A prospective randomized controlled trial with larger samples is needed to demonstrate the efficacy of these treatments for luteal phase defect.
This work was supported in part by Grants-in-Aid 17791121, 18791158, 19791153, and 20591918 for Scientific Research from the Ministry of Education, Science, and Culture, Japan.
